Abstract
Vision-based tactile sensors (VBTSs) are widely used in robotic tasks because of the high spatial resolution and relatively low manufacturing costs they offer.However, variations in their sensing mechanisms, structural dimensions, and other parameters lead to significant performance disparities between existing VBTSs. This makes it challenging to optimize them for specific tasks, as both the initial choice and subsequent fine-tuning are hindered by the lack of standardized metrics. To address this issue, TacEva is introduced as a comprehensive evaluation framework for the quantitative analysis of VBTS performance. This framework defines a set of performance metrics that capture key characteristics in typical application scenarios. For each metric, a structured experimental pipeline is designed to ensure consistent and repeatable quantification. TacEva has been applied to multiple VBTSs with distinct sensing mechanisms, and the results demonstrate its ability to provide a thorough evaluation of each design and quantitative indicators for each performance dimension. This enables researchers to preselect the most appropriate VBTS on a task-by-application basis, while also offering performance-guided insights into the optimization of VBTS design. A list of existing VBTS evaluation methods and additional evaluations can be found on our website: https://stevenoh2003.github.io/TacEva/.
